Features:

Stock Item Standard Features

• Wood Type: Strata® Rock Maple

• Frame: 24" high, 93" long, 26.5" wide

• Footbar/sprinbar: infinity footbar with revo springbar

• Carriage: custom stability padding

• Ropes & risers: retractable metal risers

• Springs: 1 blue, 3 red, 1 green, 1 yellow

• Sitting box: standard sitting box (16" w x 29" l x 11.5" h)



Loops/handles:

- padded single d-ring cotton loops (1 pair)

- padded double loops (1 pair)

- ankle Velcro cuffs (1 pair)

- thigh Velcro cuffs (1 pair)



Other:

-medium padded footstrap
- neoprene handles (1 pair)
- padded footplate
- oversized standing platform
- pre-drilled for T-bar (pre-drilled only)
- pre-drilled for tower (pre-drilled only)



Frame

•Clinicians work comfortably with a choice of 3 frame heights: 14", 18" or 24".

•Retractable metal risers are easy to calibrate and allow for quick mat conversions. Risers lock into 4 positions for accurate adjustment.

•Strata Rock Maple.

•Hand-finished frame with a top-grade catalyzed conversion lacquer and lustrous satin finish.

•3 position, tilting head rest.

•Quick-release, removable shoulder rests.

•Adjustable risers with swivel pulleys that allow variable angles of resistance - ropes can be pulled easily in any direction. Pulleys can be elevated from 2" to 13" (5cm to 33cm) above the frame.

•Built-in Standing Platform, 27" x 4.5" (69cm x 11cm), with 24" x 3.5" (61cm x 9cm) rubberized non-slip surface for safety.

•Frame pre-drilled for Tower Retrofit Kit and Proprioception T-Bar mount.

•Heavy-duty hardware throughout. Aluminum parts anodized to reduce friction, prevent oxidation, and eliminate "black dust."



Footbar / Springbar

•Infinity Footbar provides five vertical and 32 horizontal positions to fit patients of all heights, including children. As you increase or decrease the distance between carriage and footbar, the carriage travel distance remains the same.

•Easily adjusted Revo Springbar system features 5 positions with 12" range.



Carriage, Straps and Handles

•Precision carriage tracking system creates an ultra-smooth, virtually silent ride. Our 8-wheel system features four custom-built vertical wheels to support the carriage, and four adjustable sidewheels to guide the carriage smoothly down the track. All wheels are built with Abec 3 bearings.

•Padded headrest moves vertically in 3 positions: 2 above the carriage, 1 level with the carriage.

•Removable, sculpted shoulder rests.

•Carriage custom stability padding. Upholstered in heavy-gauge vinyl. Details below.

•Safety-rated climbing ropes are secured by nautical cam cleats. Rope length adjustments are quick and easy.

•Shoulder posts/handles hold straps off floor when not in use.



Springs

•Accurate springs ensure risers can consistently repeat movements.

•Exclusively offered by Balanced Body, these are the longest-lasting springs available.

•Durable nickel-plated springs with tapered ends and swivel hooks.

•5-spring format enables you to configure up to 46 resistances. Your choice of spring weights. Standard configuration: 1 blue (light), 3 red (medium), 1 Yellow (very light), 1 green (heavy).



Specifications:

Height: 24" (61cm). Can also choose heights of 18" or 14". Length: 93" (236cm), Frame Width: 27" (69cm), Footbar Width: 39.25" (100cm).

Carriage Travel Length: 102cm

​

Footbar & Springbar



Infinity Footbar ®



The Infinity Footbar® was originally designed for pediatric physical therapy, and is the most adaptable footbar available today. The Footbar adjusts along the entire length of the frame to support a whole new realm of exercise possibilities, including upper body work. Five vertical positions and 32 horizontal positions give the Infinity Footbar 160 locking positions to safely accommodate people of all heights and levels of ability, including children.



Combine the Infinity Footbar with the easy-to-use Revo Springbar for the most precise system available, or choose the more traditional No-Roll Springbar.

•Footbar diameter: 2-1/4" , with padding. Width: 39-1/4".

•5 vertical footbar positions (only 4 positions shown)

•32 horizontal footbar positions



Revo Springbar



•Carriage and Springbar are integrated - moving the Springbar moves the carriage.

•Five carriage stop positions provide 12" of adjustability from carriage to footbar, creating the ergonomically correct position for every user. For short to average height clients, use positions #1or #2. For taller clients, or those with a limited range of motion, use positions #3 - #5.

​



Optional Accessory: Proprioception T-Bar



A Balanced Body® innovation

The Proprioception T-Bar is a unique tool that enables clinicians to assess asymmetries in patients. The patient lies on the Reformer, placing the feet on the T-Bar in a weight-bearing position. The T-Bar swivels on both the horizontal and vertical axes, allowing the therapist to observe weight bearing tendencies. The T-Bar also facilitates proprioception, trunk and pelvic stabilization, and hip alignment in a dynamic environment. It can be stabilized to accommodate limitations in the foot and ankle.

Cannot be retrofitted. Available on new orders.
